Гидравлический мотор Eaton Char-Lynn 177-0198-005

<div itemprop="description"><p>Гидравлический мотор Eaton Char-Lynn 177-0198-005</p><p>Model code ADL24M20AA108K0E</p><p>Description: VIS 40 Series; (Valve-In-Star) Standard Mount Motor</p><p>ADL<span style="white-space:pre"> </span>VIS-40 MOTOR</p><p>400 cm3/r [24.4 in3/r]</p><p>STANDARD, 4 BOLT BRAKE- 169.75 PILOT DIA. WITH 4.3 PILOT LENGTH AND M16 X 2-6H THREADED HOLES ON 224.00 DIA. BOLT CIRCLE</p><p>Shaft 53.98 [2.125] DIA. FLAT ROOT SIDE FIT, 33 TOOTH, 16/32 DP 30 DEG. INVOLUTE SPLINE TO FIT ANSI B92.1 1976 CLASS 5, 73.0 MINIMUM FULL SPLINE WITH .500-13 UNC-2B THREAD IN END</p><p>1.0625-12 UN-2B SAE O-RING PORTS, SIDE PORTED</p><p>Drain SHUTTLE VALVE WITH .5625-18 UNF-2B SAE O-RING CASE DRAIN PORT</p><p>Valve reducer - SET AT 4.5 bar [65 lbf/in2]</p><p>SPRING APPLIED HYDRAULIC RELEASE WET BRAKE WITH BRAKE CAPACITY OF 20,000 lbf-in STATIC AND 150 lbf/in2 BRAKE RELEASE PRESSURE</p></div>
